| Source | Destination | Type | Port | Details |
| WEM Brokers
(Infrastructure Service) |
VDA | TCP | 49752 |
« Agent port ». Listening port on the agent host, which receives instructions from the infrastructure service. |
| BASTION
(Admin server) |
WEM Brokers
(Infrastructure Service) |
TCP | 8284 | « Administration port ». Port on which the administration console connects to the infrastructure service. |
| VDA | Netscaler WEM VIP | TCP | 8286 | « Agent service port ». Port on which the agent connects to the infrastructure server. |
| Netscaler SNIP | WEM Brokers
(Infrastructure Service) |
TCP | 8286 | « Agent service port ». Port on which the agent connects to the infrastructure server. |
| VDA | Netscaler WEM VIP | TCP | 8288 | « Cached data synchronization port ». Applicable to Workspace Environment Management 1912 and later; replaces Cache synchronization port of Workspace Environment Management 1909 and earlier. Port on which the agent cache synchronization process connects to the infrastructure service to synchronize the agent cache with the infrastructure server. |
| Netscaler SNIP | WEM Brokers
(Infrastructure Service) |
TCP | 8288 | « Cached data synchronization port ». Applicable to Workspace Environment Management 1912 and later; replaces Cache synchronization port of Workspace Environment Management 1909 and earlier. Port on which the agent cache synchronization process connects to the infrastructure service to synchronize the agent cache with the infrastructure server. |
| DIRECTOR | Netscaler WEM VIP | TCP | 8287 |
« WEM monitoring port ». Listening port on the infrastructure server used by the monitoring service. (Not yet implemented.) |
| Netscaler SNIP | WEM Brokers
(Infrastructure Service) |
TCP | 8287 |
« WEM monitoring port ». Listening port on the infrastructure server used by the monitoring service. (Not yet implemented.) |
| WEM Brokers
(Infrastructure Service) |
SQL SERVER | TCP | 1433 | To connect to WEM Database |
| WEM Brokers
(Infrastructure Service) |
Citrix Licence Server | TCP | 27000 | « Citrix License Server port ». The port on which the Citrix License Server is listening and the infrastructure service connects to validate licensing. |
| WEM Brokers
(Infrastructure Service) |
Citrix Licence Server | TCP | 7279 |
The port used by the dedicated Citrix component (daemon) in the Citrix License Server to validate licensing. |
